Product Specifications

Metric
Imperial
LENGTH less boom and steps 5 080 mm
WIDTH 2 590 mm
HEIGHT 3 450 mm
WEIGHT less attachment 17 010 kg
ENGINE Tier 4f Tigercat FPT N67 Tier 4f
151 kW (203 hp) @ 2,200 rpm (rated)
165 kW (221 hp) @ 1,900 rpm (peak)
Automatic idle down
ENGINE Tier 2 Tigercat FPT N67 Tier 2
159 kW (213 hp) @ 2,100 rpm (rated)
165 kW (221 hp) @ 1,900 rpm (peak)
Automatic idle down
ENGINE Non-certified Tigercat FPT N67 Non-certified
151 kW (203 hp) @ 2,200 rpm (rated)
Automatic idle down
COOLING Side-by-side aluminum radiator, oil cooler, charge air
cooler and A/C condenser
FAN Fixed pitch, high flow
Optional Flexxaire® variable pitch, reversing
FUEL CAPACITY 378 L
DEF CAPACITY 43 L
PUMP, MAIN Piston
PUMP, SWING Piston, pressure compensated
FILTRATION (4) Spin-on, 7 micron full-flow
CYLINDER, HOIST 178 mm (7 in) diameter
CYLINDER, STICK 152 mm (6 in) diameter
CYLINDERS, STABILIZERS (4) 165 mm (6.5 in) diameter
Bolt-on bi-directional lock valves
RESERVOIR 200 L
LENGTH less step 4 290 mm
SUPPORT BASE 3 810 mm x 4 650 mm
STABILIZER PADS 585 mm x 710 mm
SWING DRIVE 9 rpm variable, 360˚ continuous rotation
Swing priority and energy recovery
SWING BEARING 1 190 mm (47 in) ball circle diameter; Internal gear teeth
Double reduction planetary gearbox
ENCLOSURE Walk-up platform
