1055D Forwarder

Product Specifications

Metric

Imperial

Dimensions

LENGTH	9,93 m
LENGTH	32 ft 7 in
With optional 2500/2400	10,43 m
With optional 2500/2400	34 ft 3 in
With optional 3100/2400	11,03 m
With optional 3100/2400	36 ft 3 in
WHEELBASE	5,3 m
WHEELBASE	17 ft 5 in
With optional 2500/2400	5,3 m
With optional 2500/2400	17 ft 5 in
With optional 3100/2400	5,9 m
With optional 3100/2400	19 ft 4 in
WIDTH	2,94 m
WIDTH	9 ft 8 in
HEIGHT	3,8 m
HEIGHT	12 ft 5 in
GROUND CLEARANCE, With standard tires	710 mm
GROUND CLEARANCE, With standard tires	28 in
WEIGHT	20 800 kg
WEIGHT	45,850 lb

Power

ENGINE Stage V	Tigercat FPT N67 159 kW (213 hp) @ 2,100 rpm (rated) 165 kW (221 hp) @ 1,800 rpm (peak)
ENGINE Tier 2	Tigercat FPT N67 159 kW (213 hp) @ 2,100 rpm (rated) 165 kW (221 hp) @ 1,800 rpm (peak)
ENGINE Non-certified	Tigercat FPT N67 159 kW (213 hp) @ 2,100 rpm (rated) 165 kW (221 hp) @ 1,800 rpm (peak)
AIR FILTRATION	2-Stage engine air cleaner
COOLING	Side-by-side aluminum radiator, oil cooler, charge air cooler, condenser
FAN	Engine driven, variable pitch with reversing cycle
FUEL CAPACITY	200 L
FUEL CAPACITY	53 US gal
Optional	26 L
Optional	7 US gal

Power Train

TRANSMISSION	2-Speed hydrostatic mechanical Piston motor, infinitely variable
Optional	Tigercat wideRANGE® drive Variable speed hydrostatic (2) Piston motors, infinitely variable
AXLES front/rear	15 t (16 tn) balanced bogie
Optional	15 t (16 tn) Tigercat balanced bogie
DIFFERENTIAL LOCKS	Independent front and rear, friction clutch style Engage while travelling
	Low range: 6 km/h 3.7 mph high range: 18,5 km/h 11.5 mph
With optional transmission	11,4 km/h 7 mph

Hydraulic System

PUMP, DRIVE	Piston, closed loop
PUMP, MAIN	Piston
FILTRATION	(1) In-tank, 10 micron full flow
CYLINDERS, STEER	(2) 80 mm (3.15 in) bore
CYLINDERS, BLADE	(2) 95 mm (3.75 in) bore
RESERVOIR	140 L
RESERVOIR	37 US gal

Brakes

SECONDARY BRAKES	Enclosed, oil cooled
PARK BRAKE	Enclosed, oil cooled Spring applied
SERVICE BRAKE	Hydrostatic enclosed, oil cooled

Crane

STANDARD	Mesera M92FT100i with double telescope stick
REACH	10 m
REACH	32 ft 10 in
LIFT TORQUE gross	130 kN-m
LIFT TORQUE gross	95,885 lbf-ft
SLEW TORQUE gross	39 kN-m
SLEW TORQUE gross	28,765 lbf-ft
OPTIONAL	Palfinger X140F105 with double telescopic stick
REACH	10,5 m
REACH	34 ft 6 in
LIFT TORQUE gross	159 kN-m
LIFT TORQUE gross	117,270 lbf-ft
SLEW TORQUE gross	45 kN-m
SLEW TORQUE gross	33,190 lbf-ft

Grapple

STANDARD	Hultdins SG260S
OPTIONAL	Hultdins SG300S Hultdins SG360 Hultdins SG360S
ROTATOR	Indexator GV12 (Mesera crane)
Optional	Indexator GV17 (Palfinger crane)

Wagon Frame

CAPACITY	15 000 kg
CAPACITY	33,069 lb
STANDARD	2500/1900
LOAD LENGTH	4,4 m
LOAD LENGTH	14 ft 5 in
OPTIONAL	2500/2400
LOAD LENGTH	4,9 m
LOAD LENGTH	16 ft 1 in
OPTIONAL 2	3100/2400
LOAD LENGTH	5,5 m
LOAD LENGTH	18 ft

Bunk System

STANDARD	Level load, fixed
WIDTH	2,92 m
WIDTH	9 ft 7 in
LOAD AREA	4,8 m²
LOAD AREA	52 ft²
GATE	Vertical lifting, fixed width
OPTIONAL	Level load, telescopic
WIDTH minimum	2,92 m
WIDTH minimum	9 ft 7 in
LOAD AREA minimum	4,8 m²
LOAD AREA minimum	52 ft²
WIDTH maximum	3,23 m
WIDTH maximum	10 ft 7 in
LOAD AREA maximum	5,3 m²
LOAD AREA maximum	57 ft²
GATE	Vertical lifting Expandable, swing-out
WIDTH minimum	2.85 m
WIDTH minimum	9 ft 4 in
WIDTH maximum	3.09 m
WIDTH maximum	10 ft 2 in

Electrical

BATTERY	(2) 1400 CCA, 12 v
ALTERNATOR	140 amp, 24 v
SYSTEM VOLTAGE	24 v
LIGHTING	(20) LED, multiple work light modes (2) Service lights

Operator's Station

CAB	Insulated and isolation mounted Pressurized constant temperature A/C and heater Window blinds Pull-down rear sun visor Front/rear wipers and washers Emergency exit window Rear cab guard AM/FM digital stereo and auxiliary input port USB-C, 12V power point, phone holder Bluetooth® audio and hands-free calling Cooler storage
SEAT	Air ride extreme duty suspension Heated Rotating high torque with electric lock in any position Fully adjustable seat height and fore/aft, seatback recline and lumbar support, head rest Adjustable armrests Armrest mounted Tigercat joysticks and control pods
SEAT Optional	Air ride extreme duty, high capacity suspension Heated and cooled Rotating with electric lock in any position Fully adjustable seat height and fore/aft, seatback recline and air powered variable lumbar support, seat pan fore/aft and tilt, head rest height Adjustable armrests Armrest mounted Tigercat joysticks and control pods
OPERATOR CONTROLS	Ergonomic mini-joystick pods for steering, crane, grapple, blade functions (2) Foot pedals for brake and speed control Electronic control system with rear-mounted LCD colour touchscreen for machine monitoring and function adjustment

LogOn™ local wifi machine monitoring system
Power tilting engine enclosure
Power tilting cab
Power operated ladder
Fuel/water separator
Forestry-duty steel panels and covers
Cylinder oscillation locks
Towing hitch
Front recovery lugs
Vacuum pump
Centre mounted service access ladder

OPTIONAL

RemoteLog® telematics system
F30 productivity monitoring system
Hydraulic sliding gate
Diesel powered coolant heater
Electric fuel fill pump, 24 v
Engine block heater, 120 v (North America only)
Biodegradable hydraulic oil
Side window wipers
Roading package with lights, mirrors and turn signals
Camera system, front/rearVIEW
4-Point seatbelt (available for optional seat only)
Four way isolator seat suspension mounting plate
Semi-active seat suspension base (available for optional seat only)
Blade
Telescoping tail extension (2400 wagon frame only)
Tire pressure monitoring system (TPMS)
SiriusXM satellite radio (North America only)
Fire suppression system
Booster cables
Spare wheel assembly
Food heater
Front-mounted LCD colour touchscreen
