| LENGTH | 7 925 mm |
| WHEELBASE | 4 060 mm |
| WIDTH | 3 000 mm |
| HEIGHT | 3 150 |
| GROUND CLEARANCE | 555 mm |
| WEIGHT | 19 050 kg |
| ENGINE Tier 4f | Tigercat FPT N67 Tier 4f 151 kW (202 hp) @ 2,200 rpm (rated) |
| AIR FILTRATION | 2-stage engine air cleaner with heavy duty rain cap inlet |
| TOP SPEED | 19 km/h |
| COOLING | Side-by-side aluminum radiator, oil cooler, charge air cooler and A/C condenser |
| FAN | Fixed pitch, blower |
| Optional | Flexxaire® variable pitch, reversing |
| FUEL CAPACITY | 305 L |
| DEF CAPACITY | 43 L |
| TRANSMISSION | Single-speed mechanical Variable speed hydrostatic (2) variable displacement motors |
| AXLE front | Tigercat OB17, outboard planetary, barrel differential +/-15° oscillation |
| AXLE rear | Tigercat OB17, outboard planetary, barrel differential Fixed |
| DIFFERENTIAL LOCKS | Independent front and rear |
| PUMP, DRIVE | Piston |
| PUMP, MAIN 1 | Piston for all machine functions |
| PUMP, MAIN 2 | Gear for cooling |
| PUMP, COOLING | (2) Spin-on, 7 micron full-flow |
| FILTRATION | (2) Spin-on, 7 micron full-flow |
| CYLINDERS, ARCH | (2) 115 mm (4.5 in) bore |
| CYLINDERS, BLADE | (2) 95 mm (3.75 in) bore |
| RESERVOIR | 121 L |
| DYNAMIC BRAKING | Hydrostatic |
| SECONDARY BRAKES | Enclosed, oil cooled |
| PARK BRAKE | Spring applied, hydraulic release |
