Two efficient ER boom options to customize the carrier to your harvesting or processing application.
Standard two-piece boom and the optional long-reach telescopic boom for reduced machine travel and ground disturbance.
The side opening engine roof completely exposes the top and both sides of the engine, and most hydraulic components. When open, the enclosure roof serves as a spacious side service platform to work comfortably and safely.
The sloping tail profile provides additional swing clearance and obstacle avoidance while maintaining excellent balance and stability characteristics.
The unique design maintains ready access to components and daily service points within the upper assembly and engine compartment.
| LENGTH less boom | 5 640 mm |
| WIDTH | 3 390 mm |
| HEIGHT | 3 290 mm |
| GROUND CLEARANCE | 710 mm |
| WEIGHT less attachment | 31 900 kg |
| TAIL SWING RADIUS | 3 150 mm |
| ENGINE Stage V | Tigercat FPT N67 Stage V 210 kW (282 hp) @ 2,100 rpm (rated) |
| ENGINE Tier 4f | Tigercat FPT N67 Tier 4f 212 kW (284 hp) @ 2,200 rpm (rated) |
| ENGINE Non-certified | Tigercat FPT N67 Non-certified 212 kW (284 hp) @ 2,200 rpm (rated) |
| AIR FILTRATION | Precleaner and 2-stage engine air cleaner |
| COOLING | Aluminum side-by-side radiator, oil cooler and charge air cooler Removable intake debris screen |
| FAN | Hydraulically driven, automatic variable speed, reversible |
| FUEL CAPACITY | 850 L |
| DEF CAPACITY | 80 L |
| LOW RANGE | 1,8 km/h |
| HIGH RANGE | 4.0 km/h |
| PUMP, MAIN | Piston |
| PUMP, HARVESTING HEAD | Piston |
| PUMP, COOLING FAN | Gear |
| FILTRATION | (2) In-tank, 10 micron full flow |
| CYLINDER, HOIST | (2) 120 mm (4.7 in) bore |
| CYLINDER, STICK | (2) 120 mm (4.7 in) bore |
| HORSEPOWER CONTROL | Electronic speed sensing All-speed antistall |
| RESERVOIR | 295 L |
| TRACK FRAMES | R6-152-5 heavy-duty forestry Integral track guides/ramp angles |
| TRACK CHAIN | F8 203 mm (8 in) pitch sealed and greased |
| FINAL DRIVE | (2) piston motors with brake valves Infinitely variable speed |
| TRACTIVE EFFORT | 308 kN |
| GEARBOX | Triple reduction planetary type with brake |
| FRONT IDLER | Hydraulic track adjuster Spring shock absorber |
| ROLLERS, LOWER | (9) D6 single/double flange tractor type |
| SLIDES, UPPER | Optional, bolt-on |
| TRACK SHOE | 610 mm (24 in) single/double grouser |
| Optional | 710 mm (28 in) single grouser |
