Product Specifications

Metric
Imperial

Dimensions

WIDTH 3 430 mm
HEIGHT transport 3 710 mm
GROUND CLEARANCE 685 mm
WEIGHT less attachment 31 025 kg
TAIL SWING RADIUS 3 150 mm

Power

ENGINE Tier 4f Tigercat FPT N67 Tier 4f
187 kW (251 hp) @ 2,100 rpm (rated)
ENGINE Tier 2 Tigercat FPT N67 Tier 2
187 kW (251 hp) @ 2,100 rpm (rated)
ENGINE Non-certified Tigercat FPT N67 Non-certified
187 kW (251 hp) @ 2,100 rpm (rated)
AIR FILTRATION Precleaner, 2-stage engine air cleaner
COOLING Side-by-side aluminum radiator, oil cooler, charge air cooler and A/C condenser
FAN Hydraulic driven automatic variable speed, reversible
FUEL CAPACITY 600 L
DEF CAPACITY 46 L

Top Speed

LOW RANGE 2,5 km/h
HIGH RANGE 4,5 km/h

Hydraulic System

PUMP, MAIN Piston, load sensing
PUMP, COOLING FAN Gear
FILTRATION (5) Spin-on, 7 micron full flow
(1) Water absorbing
CYLINDERS, HOIST (2) 120 mm (4.7 in) bore
CYLINDER, STICK (1) 130 mm (5.1 in) bore
HORSEPOWER CONTROL Electronic speed sensing
RESERVOIR 225 L

Undercarriage

TRACK FRAMES F6-152 heavy duty forestry
Integral track guide
TRACK CHAIN F8/D6D 203 mm (8 in) pitch
FINAL DRIVE (2) Axial piston motors
Infinitely variable speed
GEARBOX Triple reduction planetary with brake
FRONT IDLER Hydraulic track adjuster
Spring shock absorber
ROLLERS, UPPER (2) D6 excavator type
ROLLERS, LOWER (9) D6 excavator type
SLIDES, UPPER Optional, bolt-on
TRACK SHOE 610 mm (24 in) single grouser/double grouser
Optional 710 mm (28 in) double grouser
760 mm (30 in) double grouser tri-track/triple grouser
915 mm (36 in) triple grouser/triple grouser tri-track

+ ALL

Resources

loader-icon

The Full Package


BTB catches up with Sunshine Logging Ltd. after the Kaslo, British Columbia based company purchased two Tigercat 850 processors, each equipped with the Tigercat 568 processing head.


850 Processor Walk-around


Tigercat product manager, Aaron Wilkes takes us on a walk-around of the 850 processor. Learn about the key features that set the Tigercat 850 roadside processor apart from excavator conversions.


Tigercat Seat Adjustments


With the exception of forwarders and harvesters, all current 2025 Tigercat models are equipped with a common operator’s seat. In this video, to help you get the best performance from the seat, we are going to take you through the adjustments and point out some differences specific to certain machine models.
