234B Loader

Product Specifications

Metric

Imperial

Dimensions

LENGTH	4 900 mm
LENGTH	193 in
WIDTH	2 590 mm
WIDTH	102 in
HEIGHT	3 530 mm
HEIGHT	139 in
WEIGHT	15 130 kg
WEIGHT	33,350 lb

Power

ENGINE Tier 4f	Tigercat FPT N45 Tier 4f 125 kW (168 hp) @ 2,200 rpm (rated) 129 kW (173 hp) @ 1,900 rpm (peak) Automatic idle down
COOLING	Side-by-side aluminum radiator, oil cooler, charge air cooler and A/C condenser
FAN	Fixed pitch, high flow
Optional	Flexxaire® variable pitch, reversing
FUEL CAPACITY	378 L
FUEL CAPACITY	100 US gal
DEF CAPACITY	43 L
DEF CAPACITY	11 US gal

Hydraulic System

PUMP, MAIN	Piston
PUMP, SWING	Piston, pressure compensated
FILTRATION	(4) spin-on, 7 micron full-flow
CYLINDER, HOIST	165 mm (6.5 in) bore
CYLINDER, STICK	140 mm (5.5 in) bore
CYLINDERS, STABILIZERS	(4) 165 mm (6.5 in) bore, bolt-on bi-directional lock valves
RESERVOIR	200 L
RESERVOIR	55 US gal

Subframe

LENGTH less step	4 290 mm
LENGTH less step	169 in
SUPPORT BASE	3 810 mm x 4 650 m
SUPPORT BASE	150 in x 183 in
STABILIZER PADS	585 mm x 710 mm
STABILIZER PADS	23 in x 28 in

Rotating Upper

SWING DRIVE	10 rpm variable, 360˚ continuous rotation Swing priority and energy recovery
SWING BEARING	1 190 mm (47 in) ball circle diameter Internal gear teeth Double reduction planetary gearbox
ENCLOSURE	Walk-up platform
COUNTERWEIGHT	910 kg
COUNTERWEIGHT	2,000 lb

Boom System

MAXIMUM REACH	9 750 mm
MAXIMUM REACH	32 ft
BARE PIN LIFT at 7,62 m	5 670 kg
BARE PIN LIFT at 25 ft	12,500 lb

Electrical

BATTERY	(2) 950 CCA, 12 v
ALTERNATOR	80 amp, 24 v
SYSTEM VOLTAGE	24 v
LIGHTING	Halogen, (2) boom mounted, (3) cab mounted, (1) engine house (1) service, engine house
Optional	LED lighting package

Insulated, pressurized and isolation mounted
Forward sloping, tinted polycarbonate windshield with intermittent wiper
Sliding tinted side windows
Polycarbonate skylight
Window blinds for windshield and skylight
A/C, heater, defroster and pressurizer
3-speed fan
Dome light
Cell phone holder
(2) 12 v power points; CB radio
AM/FM digital stereo and auxiliary input port
Bluetooth® audio and hands-free calling
Electronic control system with colour LCD display screen for machine monitoring and function adjustment

SEAT

Heavy duty suspension, fully adjustable, heated and cooled

Operator Controls

BOOM	Hydraulic joystick
Optional	Electronic joystick
SWING	Pilot valve, foot operated
STABILIZERS	Electric switches

Other Equipment

STANDARD	LogOn™ local wifi machine monitoring system Delimber/bar saw slasher hydraulics
OPTIONAL	RemoteLog® telematics system Tigercat LG4053, LG5057T grapples, continuous rotation Other grapples available Live Heel Grapple saw hydraulics Circle saw slasher hydraulics Self-propelled hydraulics High Output LED lighting package 760 mm (30 in) cab riser Cold weather kit
