Using the 610 platform, Tigercat and Clohse Group help a diverse group of French loggers fulfill a wide variety of skidding requirements, while providing excellent after sale support.
| LENGTH | 8 470 mm |
| WHEELBASE | 4 225 m |
| WIDTH | 2 850 mm |
| HEIGHT | 3 200 mm |
| GROUND CLEARANCE | 540 mm |
| WEIGHT | 18 750 kg |
| ENGINE Stage V | Tigercat FPT N67 155 kW (208 hp) @ 2,200 rpm (rated) |
| AIR FILTRATION | 2-stage engine air cleaner with heavy duty rain cap inlet, optional pre-cleaner |
| TOP SPEED | 19 km/h |
| COOLING | Side-by-side aluminum radiator, oil cooler, charge air cooler and A/C condenser |
| FAN | Fixed pitch, blower |
| Optional | Flexxaire® variable pitch, reversing |
| FUEL CAPACITY | 255 L |
| DEF CAPACITY | 46 L |
| TRANSMISSION | Single-speed mechanical Variable speed hydrostatic (2) Variable displacement motors |
| AXLE front | Tigercat IB15, inboard planetary, barrel differential Fixed |
| AXLE rear | Tigercat IB17, inboard planetary, barrel differential Fixed |
| DIFFERENTIAL LOCKS | Independent front and rear |
| CENTRE JOINT OSCILLATION | +/-12.5° |
| PUMP, DRIVE | Piston |
| PUMP, MAIN 1 | Piston for all machine functions |
| PUMP, MAIN 2 | Gear for cooling |
| FILTRATION | (4) Spin-on, 7 micron full-flow |
| CYLINDERS, STEER | (2) 85 mm (3.25 in) bore |
| CYLINDERS, BLADE | (2) 90 mm (3.5 in) bore |
| CYLINDERS, SHIELD | 127 mm (5 in) bore |
| CYLINDERS, FAIRLEAD | 85 mm (3.25 in) bore |
| RESERVOIR | 126 L |
| DYNAMIC BRAKING | Hydrostatic |
| SECONDARY BRAKES | Enclosed, oil cooled |
| PARK BRAKE | Inline Spring applied/hydraulic release |
