Product Specifications

Metric
Imperial

Dimensions

LENGTH 7770 mm
WHEELBASE 4 240 m
WIDTH 2 850 mm
HEIGHT 3 150 mm
GROUND CLEARANCE 540 mm
WEIGHT 18 645 kg

Power

ENGINE Stage V Tigercat FPT N67 155 kW
(208 hp) @ 2,200 rpm (rated)
AIR FILTRATION 2-stage engine air cleaner with heavy duty rain cap inlet, optional pre-cleaner
TOP SPEED 19 km/h
COOLING Side-by-side aluminum radiator, oil cooler, charge air cooler and A/C condenser
FAN Fixed pitch, blower
Optional Flexxaire® variable pitch, reversing
FUEL CAPACITY 315 L
DEF CAPACITY 46 L

Power Train

TRANSMISSION Single-speed mechanical
Variable speed hydrostatic
(2) Variable displacement motors
AXLE front Tigercat IB15, inboard planetary, barrel differential
Fixed
AXLE rear Tigercat IB17, inboard planetary, barrel differential
Fixed
DIFFERENTIAL LOCKS Independent front and rear
CENTRE JOINT OSCILLATION +/-12.5°

Hydraulic System

PUMP, DRIVE Piston
PUMP, MAIN 1 Piston for all machine functions
PUMP, MAIN 2 Gear for cooling
FILTRATION (4) Spin-on, 7 micron full-flow
CYLINDERS, ARCH (4) 100 mm (4 in) bore (dual function)
CYLINDERS, STEER (2) 83 mm (3.25 in) bore
CYLINDERS, BLADE (2) 89 mm (3.5 in) bore
RESERVOIR 126 L

Brakes

DYNAMIC BRAKING Hydrostatic
SECONDARY BRAKES Enclosed, oil cooled
PARK BRAKE Inline
Spring applied/hydraulic release

+ ALL
