Product Specifications

Metric
Imperial

Dimensions

LENGTH less boom 4 930 mm
WIDTH 3 390 mm
HEIGHT 3 330 mm
GROUND CLEARANCE 760 mm
WEIGHT less attachment 28 350 kg
TAIL SWING RADIUS 2 095 mm

Power

ENGINE Stage V Tigercat FPT N67 Stage V
217 kW (291 hp) @ 2,200 rpm (rated)
ENGINE Tier 4f Tigercat FPT N67 Tier 4f
212 kW (284 hp) @ 2,200 rpm (rated)
ENGINE Non-certified Tigercat FPT N67 Non-Certified
212 kW (284 hp) @ 2,200 rpm (rated)
AIR FILTRATION Precleaner and 2-stage engine air cleaner
COOLING Aluminum side by side radiator, oil cooler, charge air cooler
Removable intake debris screen
FAN Hydraulically driven
Automatic variable speed and reversing cycle
FUEL CAPACITY 585 L
DEF CAPACITY 80 L

Top Speed

LOW RANGE 1,9 km/h
HIGH RANGE 4,2 km/h

Hydraulic System

PUMP, MAIN Piston
PUMP, SAW Piston
PUMP, COOLING FAN Piston
PUMP, CLAMP/ACCUM. ARMS Piston
FILTRATION (5) Spin-on, 7 micron full flow
(1) water absorbing
CYLINDERS, HOIST 140 mm (5.5 in) bore
CYLINDERS, STICK/ER (2) 110 mm (4.3 in) bore
CYLINDER, TILT 130 mm (5.2 in) bore
HORSEPOWER CONTROL Electronic speed sensing
All-speed antistall
RESERVOIR 204 L

Undercarriage

TRACK FRAMES R6-152-5 heavy-duty forestry
Integral track guides/ramp angles
TRACK CHAIN F8/D6D 203 mm (8 in) pitch sealed and greased
FINAL DRIVE (2) axial piston motors
Infinitely variable speed
TRACTIVE EFFORT 280 kN
GEARBOX Triple reduction planetary type with brake
FRONT IDLER Hydraulic track adjuster
Spring shock absorber
ROLLERS, LOWER (9) D6 single and double flange tractor type
SLIDES, UPPER Replaceable, bolt-on
Optional rollers
TRACK SHOE 610 mm (24 in) single/double grouser
Optional 710 mm (28 in) single grouser tri-track
760 mm (30 in) double grouser tri-track
915 mm (36 in) triple grouser tri-track

+ ALL
